Speedster®7t FPGAs are optimized for high-bandwidth workloads and
eliminate the performance bottlenecks associated with traditional FPGAs.
The
Speedster7t FPGA family is optimized for high-bandwidth workloads and
eliminates the performance bottlenecks associated with traditional
FPGAs. Built on the TSMC 7nm FinFET process, Speedster7t FPGAs feature a
revolutionary new 2D network-on-chip (2D NoC), an array of new machine
learning processors (MLPs) optimized for high-bandwidth and artificial
intelligence/machine learning (AI/ML) workloads, high-bandwidth GDDR6
interfaces, 400G Ethernet and PCI Express Gen5 ports. The 2D NoC
connects all of the interfaces to over 80 access points in the FPGA
fabric to deliver ASIC-level performance while retaining the full
programmability of FPGAs. Get started today with the VectorPath
accelerator card, featuring the Speedster7t FPGA.
|
2D Network on Chip (2D NoC)
|
High-Speed Data Interfaces
|
Machine Learning Processors (MLPs)
|
-
>20 Tbps bandwidth
-
Interconnects, I/O, memory, internal functional blocks and FPGA fabric.
-
Reduces routing congestion vs. traditional FPGAs by over 40%
-
Simplifies FPGA design
|
-
PCIe Gen5
-
112 Gbps SerDes channels
-
400G Ethernet
-
GDDR6 memory
-
Up to eight controllers
-
Up to 4 Tbps bandwidth
|
-
Native support for integer, floating point, bfloat16 and block floating point
-
Speeds up to 750 MHz with co-located block RAM
-
Fully fracturable integer multiplier/accumulator
|
|
|
|
|
Speedster7t Product Table
|
Feature
|
AC7t700(1)
|
AC7t800
|
AC7t1400(1)
|
AC7t1500
|
|
Logic Density
|
|
System Logic Cells (SLCs)
|
730k
|
730k
|
1,546k
|
1,546k
|
|
6-Input Look-Up Tables (LUTs)
|
326k
|
326k
|
692k
|
692k
|
|
|
|
32-bit (INT)(3)
|
864
|
864
|
2,560
|
2,560
|
|
16-bit (FP or TensorFlow bFloat)(4)
|
1,728
|
1,728
|
5,120
|
5,120
|
|
24-bit (FP)
|
1,728
|
1,728
|
5,120
|
5,120
|
|
16-bit (INT)
|
3,456
|
3,456
|
10,240
|
10,240
|
|
8-bit/6-bit (INT or FP)
|
13,824
|
13,824
|
40,960
|
40,960
|
|
4-bit (INT or Block FP)
|
27,648
|
27,648
|
81,920
|
81,920
|
|
On-Chip Memory
|
|
Total Memory
|
86 Mb
|
86 Mb
|
195 Mb
|
195 Mb
|
|
Local RAM (LRAM) Blocks (2.3 kb)
|
864
|
864
|
2,560
|
2,560
|
|
Block RAM (BRAM) Blocks (72 kb)
|
1,152
|
1,152
|
2,560
|
2,560
|
|
High-Performance Interfaces
|
|
112 Gbps SerDes
|
24
|
24
|
32
|
32
|
|
DDR4/5 Memory Channels
|
1 (DDR4/DDR5)
|
1 (DDR4/DDR5)
|
1 (DDR4)
|
1 (DDR4)
|
|
GDDR6 Memory Channels
|
6 (1.5 Tbps)
|
6 (1.5 Tbps)
|
16 (4 Tbps)
|
16 (4 Tbps)
|
|
PCIe (Gen5)
|
1 (×8)
|
1 (×16)
|
1 (×8)
|
2 (×8 and ×16)
|
|
Ethernet (10 Gbps to 400 Gbps)
|
8 lanes
400G (max)
|
8 lanes
2 × 400G (max)
|
16 lanes
400G (max)
|
16 lanes
2 × 400G (max)
|
|
Security
|
|
Inline Cryptography (25G)
|
Hard IP
|
Hard IP
|
None
|
Soft IP
|
|
Performance
|
|
2D NoC bandwidth (Tbps)
|
12
|
12
|
21
|
21
|
|
ML TOps: INT-8 or bFloat-16(5)
|
20.5
|
20.5
|
61
|
61
|
|
Packaging
|
|
42.5 × 42.5 mm BGA
|
1,677 balls
|
1,677 balls
|
-
|
-
|
|
52.5 × 52.5 mm BGA
|
-
|
-
|
2,597 balls
|
2,597 balls
|
|
Table Notes
-
AC7t700 and AC7t1400 SerDes total device bandwidth limited to 500 Gbps
-
Resources per number format
-
INT - Integer
-
FP - Floating point
-
ML - Machine learning
Next-Generation FPGAs from Achronix
The next generation of Achronix FPGA technology brings many innovations to the FPGA industry including:
-
Power and performance optimized 2D NoC technology providing fast data transport across the entire FPGA and die-to-die interconnects
-
Enhanced DSP and ML processor arrays offering low-power, high-performance compute capabilities
-
New, state-of-the-art, security and encryption features to enable fully secure programming and communication protocols
-
Support for the highest performance SerDes (up to 112 Gbps), Ethernet (2 x 400 GE) and PCIe (Gen5)
-
Support for the highest bandwidth external memory interfaces (GDDR6 and DDR5)
